Wind Power Generation
Windwheel diameter 1m
Number of Blade 3pcs
Length of Blade 1.26m
Blade material Aluminum Alloy
Generator permanentmagnet alternator generator
Rated output 400W
Rated wind speed 12.5m/s
Min, generatable wind speed 3m/s
Endurable wind speed 60m/s
Mass of windwheel 40kg
Solar Battery Module
Nominal maximum output 130W
Nominal max. output acting voltage 17.6V
Nominal max. output acting current 8.02A
Mass of module 12.2kg
External dimension (W x D x H) 1425 x 652 x 36
Controller (ATS)
Output voltage 220/240
Output frequency 50Hz
continuous outpuyt capacity 1750VA
Maximum output capacity 2500VA
Battery (DS) : Voltage/Ampere 12V/10A
Ambient condition
Ambient temperature -10℃~+40℃
Relative humidity 95% (max)
